Calculation field : function reference

# Calculation field : function reference

There are several functions that you can use in a calculation field. The functions can be categorized as Mathematical functions, Conditions, and date functions.

Note that the arguments to these functions can be fields in the form or  constants.

## General functions

#### if_else(condn, true_part, false_part)

Evaluates the condition 'condn' and returns 'true_part' or 'false_part' depending on the evaluation result of the condition.

Examples:

if_else(total>1000,10,0)

if the value entered in the field total is greater than 1000, return 10.

If total is less than or equal to 1000, return 0.

#### is_empty(input_name)

Checks whether the input field is empty or not. Returns 1 if empty 0 if there is value in the field. If the input is only spaces, it is taken as empty.

#### map_to_number(mapstr,value)

map from string value to number. This function is useful for including radio groups or list boxes in a formula.

The format of the string value map is "string1 => value1, string2=>value2, string3 => value3 " and so on.

Example:

imagine you have a 'subscription' radio option with three cases: none, basic and advanced with cost 0, 100 and 200.

The following call can be used in this case:

## Date Functions

#### days_between(date1,date2)

returns the number of days between two dates ( result = date1 - date2 )

The return value can be negative if date1 is before date2. date1 and date2 should be DateFields.

#### days_from_today(other_date)

returns the number of days from today to other_date. (that is, result = other_date - today) The return value can be negative if other_date is in the past.

#### age(date)

returns the number of years after date. This function can be used to determine the age if you have a date of birth field in your form. If the date is in the future, the return value will be negative.

#### month(date)

returns the month of the date. 1 for January and 12 for December. For example, if date is 2/1/2017 (and the date format setting is mm/dd/yyyy) month() function returns 2

#### year(date)

returns the year part of the date. if date is 2/1/2017, the function returns 2017

#### day_of_month(date)

If date is 2/15/2014 (in mm/dd/yyyy format) the function returns 15, the day of the month part.

#### day_of_week(date)

returns the day of the week. 1 for Sunday, 7 for Saturday. If date is 17 July 2014, the function will return 5, representing Thursday.

## Mathematical functions

The mathematical functions are for doing general mathematical operations.

#### max(p1,p2,p3,...)

find the maximum value from the arguments. You can pass any number of arguments.

#### min(p1,p2,p3,...)

find the minimum from the arguments. You can pass any number of arguments.

#### avg(p1,p2,p3,...)

find the average of the passed-in values. You can pass any number of arguments.

#### abs(num)

Returns the absolute value of the number

Examples:

abs(-3) is 3

abs(3) is 3

abs(-3.44) is 3.44

#### ceil(num)

returns the number rounded upwards to the nearest integer

Example:

ceil(2.1) is 3

ceil(2.001) is 3

ceil(-2.001) is -2

#### floor(num)

returns the value of the number rounded downwards to the nearest integer

Examples:

floor(2.1) is 2

floor(2.001) is 2

floor(-2.001) is -3

#### round(num,dec)

rounds the number to dec decimal places.

num: the number that should be rounded.

dec: the number of decimal places to round

Examples:

round(2.1115,2) is 2.11

round(2.1115,3) is 2.112

round(2.5,2) is 2.5

round(2.5,0) is 3

#### pow(x,y)

returns the value of x to the power of y.

Examples:

pow(3,2) is 9

pow(3,3) is 27

#### sqrt(x)

calculates the square root of x

#### log(x)

calculates the natural logarithm(Base E) of x

#### perc_of(total,perc)

returns the 'perc' percentage of total. For example, to find the 10% of amount, the formula is perc_of(amount,10)

Example:

perc_of(1000,10) is 100

#### find_perc(fraction,max)

calculate the percentage value of fraction, given max.

for example: find_perc(100,1000) is 10

## Trigonometric functions

The following trigonometric functions also are supported

sin(x)

cos(x)

tan(x)

asin(x)

acos(x)

atan(x)

## String literal functions

Simfatic Forms 5 adds String literal functions to the calculation field. Here are the string functions that are supported

#### concat(str1,str2,str3,str4 ...)

The concat function concatenates multiple strings in to one. For example, if you have First name and Last name fields in the form and want to create a Full name field, here is the formula that you can use:

concat(FirstName,str(" "),LastName)

Notice the str(" ") You can't use string literals directly in the formula. In order to use a string literal in the calculation, use str() function.

#### str(" literal " )

The str function is to use a string literal in the calculation. For example, if you want to check the input in a text field is 'yes', here is the formula

if_else(txt == str("yes"),1,0)

## Deprecated Functions

These functions are for backward compatibility. There are alternatives for these functions in the current version.

#### format_currency ( amount, add_comma )

The decimal places are rounded to two digits. (example: 12.129 becomes 12.13)

If there is only one digit after the decimal point, 0 is appended.(example:12.5 becomes 12.50)

The currency format depends on the localization settings selected in the Form:General page->Localization tab

In the current version, you can enable 'Format as currency' in the calculation field properties box instead of using this function.

Examples:

format_currency(12,0)

\$12.00

format_currency(12.1,0)

\$12.10

format_currency(12.129,0)

\$12.13

format_currency(1000,0)

\$1,000.00

#### is_checked(checkbox_name)

Useful for including a checkbox in a formula. Returns 1 if the check box is selected, 0 otherwise.

Example:

Suppose subscribing to the newsletter enables a 10% discount. You can do this using formula:

is_checked(checkBoxSubscribe) * 10

In the current version, you can directly use the check box in the calculation formula

example chkSubscribe * price

#### is_checked_grp(value,checkbox_group)

This function can be used for including a check box group in a formula. It checks whether the check box with the given value is selected. Remember that one can select multiple options from a check box group. Returns 1 if selected, 0 otherwise.

Example:

is_checked_grp("PCMag",Magazines)

In the current version, you can directly use the check box in the calculation formula

example Magazines["PCMag"] * price
